Description
Blue Sea Terminal Feed Through Connector - 5/16"-18 Studs
Eliminates chafe and provides strain relief when passing high current through hulls, decks and bulkheads
- Perfect for passing high current cables through hulls, decks and bulkheads
- Large cables passed through holes are subject to chafing even when protective grommeting is used. Terminal Feed Through Connectors eliminate chafing and provide excellent strain relief for the cable
- Large size terminals have a mounting face that can be gasketed or bedded to provide a water tight installation
- Rated IP66 — withstands water from heavy seas
##Specifications##
| Specifications | |
|---|---|
| Amperage | 250A |
| Colour | Black |
| Maximum Voltage | 48V DC |
| Stud Size | 5/16"-18 |
| Base Material | Reinforced Thermoplastic |
| Recommended Torque | 100 in-lb (11.3 N·m) |
| Stud Material | Tin-Plated Copper Alloy |
| Weight | 0.30lb (0.14 kg) |
