Description
Blue Sea DualBus Common Bus Bar - 100A, 5 Circuit
Combines 2 buses on one block
- Combines negative & positive buses for DC Systems & neutral & ground buses for AC systems
- CE Certified
| Maximum Voltage | 300V AC 48V DC |
| Number of Screw Terminals | 5 per bus |
| Terminal Type | #8-32 Screw |
| Continuous Rating | 100A |
| Base Material | UL 94-V0 Rated, Glass Reinforced Thermoplastics |
| Bus Material | Tin-Plated Copper CDA 110 / UNS 11000 |
| Screw Terminal Torque | 15 in-lb (1.69 Nm) |
| Height | 5⁄8 in (15.88 mm) |
| Weight | 0.17lb (0.08 kg) |
