Description
Lewmar Stainless Portlight Size
Manufactured from mirror polished stainless steel, these portlights are supplied fitted with friction hinges and low profile handles. The portlights present a modern clean look, thanks to the hinge positioning and integrated handles which allow a clear view. This range can be installed on 9mm to 30mm thick surfaces.
Features
• Join-less polished stainless steel outer frame
• Handles and hinges are fitted to the outer edge of the lens for unobstructed visibility
• Quick action closing handles
• Friction hinges to hold the smoked acrylic window open
• White ABS trim (Chrome for size 8), including insect screen
• CE Approved for Area 2A
|
Part Number
|
Size
|
Version
|
Trim Colour
|
Outside X x Y L x W mm
|
Cut Out X1 x Y L x W mm
|
Radii R mm
|
Radii R1 mm
|
Height Z mm
|
Acrylic mm
|
|---|---|---|---|---|---|---|---|---|---|
| 170980-BLA | 0 | Opening | White | 176 x 323 | 156 x 303 | 62 | 52 | 4 | 8 |
| 170982-BLA | 1 | Opening | White | 191 x 367 | 171 x 347 | 62 | 52 | 4 | 8 |
| 170984-BLA | 1RE | Opening | White | 191 x 367 | 171 x 347 | 95.5 | 85.5 | 4 | 10 |
| 170986-BLA | 7RE | Opening | White | 191 x 425 | 171 x 405 | 95.5 | 85.5 | 4 | 10 |
| 170987-BLA | 7RE | Fixed | White | 191 x 425 | 171 x 405 | 95.5 | 85.5 | 4 | 10 |
| 170988-BLA | 8 | Opening | Chrome | 196 x 452 | Refer Instructions | N/A | - | 4 | 10 |
| 170989-BLA | 8 | Fixed | Chrome | 196 x 452 | Refer Instructions | N/A | - | 4 | 10 |
