RELAXN Digital Membrane Touch Control Panel - 10 Switch
The RELAXN Digital Membrane Touch Control Panel features a 10-gang touch interface with LED indicators, designed for marine, automotive, and industrial applications. Each switch can be programmed as a momentary or standard on/off switch, providing maximum flexibility. The ultra-compact panel, paired with a separate control box, delivers reliable operation with IP67 water and dust resistance, LED backlighting, and built-in protection for safe and efficient performance.
##features##
Features
- 10-gang membrane touch switches with LED indicators for clear status display.
- Each switch programmable as momentary or standard on/off for versatile control.
- Ultra-compact panel design with backlighting for enhanced visibility.
- Control box can be installed in any dry location, featuring quick-connect terminals for easy setup.
- LED indicators protected with 10A PPTC fuses for safe operation.
- IP67 rated for water and dust resistance, suitable for harsh environments.
- Includes 60-piece assorted label set, mounting hardware, and 1m micro-USB cable.
##features##
## Specifications##
Specifications
| Part No. | 530692 |
| Switch Positions | 10P |
| Volts | 12V / 24V |
| Max Amps | 60A |
| Panel (W x H) | 130mm x 75mm |
| Cut Out Dia. | 15mm |
| Control Box (L x W x H) | 214mm x 95mm x 29mm |
| Unit Qty | 1 |
| Note | Each switch programmable as momentary or standard on/off. Control box must be installed in a dry area. LED indicators with 10A PPTC protection, backlighting, mounting hardware, and 1m micro-USB cable included. IP67 rated. |
