Description
Airmar 12 Degrees Tilted Element 50/200kHz - Mix and Match Plug 1kW Transducer, DT
Step up to a 1 kW—without a fairing! This 1 kW, flush-mount transducer is perfect for fast, trailered, tournament and sport-fishing vessels that cannot accommodate a High-performance Fairing. The flush-mounted, stainless steel housing extends less than 6.35 mm (1/4") outside your hull, so it can sit on trailer rollers and bunks. The ceramic arrays are tilted inside the housing, providing the perfect vertical beam with maximum energy on what is directly below the boat.
Available in three Tilted Element models:
- Fixed 20° tilted version for 16 to 24° hull deadrise angles
- Fixed 12° tilted version for 8 to 15° hull deadrise angles
- Fixed 0° tilted version for 0 to 7° hull deadrise angles
Features
- Depth and fast-response water-temperature sensing
- 1 kW of power
- Dual-frequency elements:
- 50 kHz with a wide 22° beamwidth for depth performance to 549 m (1800')
- 200 kHz with a 6° beamwidth for depth performance to 244 m (800')
- Interfaces to any 600 W or 1 kW echo sounder
- Engineered for center-console and trailered boats
- Low-profile design extends less than 6.35 mm (1/4") below the hull
- No effect on boat’s running performance
- Stainless steel housing for use in all hull materials
- Available in a bronze housing (B164) for use in a fiberglass or wood hull
- Patented Xducer ID® technology
## Specifications##
Specifications
Power Rating: 1 kW
Max Deadrise Angle: 24°
Housing: Stainless Steel
Functions: Depth, Temperature
Hull Material: Compatible w/ all hull materials
Max Vessel LOA: Up to 11 m (36')
Acoustic Window: Urethane
Common Use: Fishing
Conventional Beam: 22°x20°/6°
Max Deadrise: Up to 24°
Max Depth: Low frequency- 549 m (1800'), High frequency- 244 m (800')
Mounting Style: Tilted Element Thru-Hull
Retractable housing: No
Single or Dual Frequency: Conventional Dual Frequency
Tilted Element: Yes
Weight: 2.7 kg (6 lb.)
