Description
B&G Hercules Expansion Module
The NEW Hercules® Expansion processor allows integration of additional sensors and expansion of sailing systems for racing or cruising.
The Expansion provides a comprehensive set of analogue, serial and digital interfaces for enhanced integration with a primary sailing processor – and is compatible with Triton™ Edge™ and Hercules® sailing processors.
## Features##
Features
- Dual Ethernet ports (100Mbps)
- 9 x 12-bit analogue channels
- 2 x Serial I/O channels
- 2 x Configurable alarm outputs
- 1 x Crew overboard input
- 12/24V Power Supply
## Features##
## Specs##
Specs
Approvals
| Compliance | IEC/EN 60945 |
|---|
Connectivity
| NMEA 0183 Sentences supported | Input: HDG, HDT, ROT, THS, GGA, GLL, GSA, GSV, RMB, RMC, VTG, ZDA, AAM, APB, BWC, XTE, DPT, MTW, VHW, VLW, MWD, MWV, VDR, XDR. Output: HDG, HDT, THS, GGS, GLL, GSA, GSV, RMA, RMB, RMC, VTG, ZDA, AAM, APB, BOD, BWC, XTE, DPT, MTW, VHW, MWV, XDR. |
|---|---|
| Ethernet | 2 x 100Mbit |
| NMEA 0183 | 2x Tx, 2x Rx NMEA 0183, Baud Rates 4,800 - 115,198 |
| PC Connectivity | 1x Ethernet (webserver) |
Electrical
| Recommended Fuse Rating | 3A |
|---|---|
| Supply Voltage | 12/24V DC (9.0 - 31V DC) |
Environment
| Operating Temperature Range | -15 to +55ºC (+5 to +131ºF) |
|---|---|
| Storage Temperature Range | -40 to +85ºC (-40 to +185ºF) |
| Waterproof rating | IPX6 and IPX7 |
MFD
| Compass Safe Distance - Metric, imperial | 500mm (19.6') |
|---|
Physical
| Dimensions (W x H x D) | 230 x 192 x 63mm (9 x 7.6 x 2.5") |
|---|---|
| Mounting Type | Surface Mount |
| Weight | 0.7 kg (1.5 lbs) |
Other
| Warranty Period | 2 Years |
|---|---|
| Interface | Webserver |
