Description
Blue Sea m-Series Mini Dual Circuit Battery Switch
311 Amps continuous rated battery switches for simultaneously switching two isolated battery banks or circuits
- Simultaneously switches two isolated battery banks or circuits.
- May be used to switch the positive and negative conductors for required applications
- Simultaneously switches two isolated battery banks or combines battery banks to all loads
- CAN NOT be used to switch and positive conductors due to its combine feature.
Features
- Tin-plated copper studs for maximum conductivity and corrosion resistance Studs
- Accept 3/8" (M10) ring terminals One-piece stainless flange nuts ensure safe and secure connections
- Isolating cover protects rear contacts
- Breakout tabs allow wire
- Access in any direction
- 6 Circuit label set included (not included with 6005 and 6005200).
BS-6010B Red
BS-6010200 Black
| Switch Type | Dual Circuit |
| Colour | Red, Black |
| Switch Positions | 2 |
| Battery Combine | No |
| Alternator Field Disconnect | No |
| Maximum Voltage | 32V DC |
| Stud Size | 3/8" |
| Terminal Stud Torque | 120 in-lb (13.56 Nm) |
| Continuous Rating | 300A |
| Intermittent Rating | 450A (5 min) |
| Cranking Rating 30 sec | 675A per circuit |
| Battery Inputs | 2 |
| Cable Clearance For 4/0 AWG Cables | 1.12in (28.45 mm) |
| Cable Size to Meet Ratings | 4/0 AWG (120mm²) |
| Mounting Holes | Accept #10 Screw |
| Stud Material | Tinned Copper |
| Stud Torque | 120 in-lb (13.56 Nm) |
| Terminal Stud Size | 3/8" - 16 (M10) |
| Weight | 0.80lb (0.36 kg) |
