Description
Simrad NSS 4 Flush Mount Bezel from NSS Evo 3s
The NSS 4 is a smaller overall size to the NSS Evo 3s and mounting holes are visible
This is a bevel shroud to cover the holes, with glue to stick down
2 sizes available for the 12 inch and the 16 inch models
## Mounting##
## Mounting##
## Specifications - No Sonar##
Display
| Resolution (px) | 1280 x 800 |
| Brightness | >1200 nits |
| Touchscreen | Full touchscreen (multi-touch) |
| Viewing angles in degrees (typical value at contrast ratio = 10) | 80° top/bottom, 80° left/right |
Electrical
| Supply voltage | 12/24 V DC (10 - 31.2 V DC min - max) |
| Recommended fuse rating | 5 A |
| Maximum power consumption | 40 W |
| Protection | Reverse polarity and over-voltage (max 32 V) |
Environmental
| Operating temperature | -15°C to 55°C (5°F to 131°F) |
| Storage temperature | -20°C to 60°C (-4°F to 140°F) |
| Waterproof rating | IPX6 and IPX7 |
| Shock and vibration | 100,000 cycles of 20 G |
Interface and connectivity
| GPS | 10 Hz GNSS receiver for GPS and GLONASS, supports combinations with Galileo, Beidou, QZSS. SBAS (WAAS) |
| Wi-Fi® | Wi-Fi 5 (IEEE 802.11ax) |
| Ethernet | 1 port (X-Coded M12 GbE) |
| 1 port (yellow, 5-pin) | |
| Echosounder | No internal Echosounder. Compatible network echosounder required if needed |
| NMEA 2000® | 1 port (Micro-C connector) |
| Data card slot | 2x (microSD®, SDHC®) |
| USB | 1 port Data /Video Out |
| HDMI® | 1 port (video input) |
## Specifications - No Sonar##
## NSS4 12 Dimensions##
Physical
| Dimensions (display only) w x h x d | 338.9 mm x 208.4 mm x 84.8 mm (13.34″ x 8.20″ x 3.34″) |
| Dimensions (with bracket) w x h x d | 367.8 mm x 232.8 mm x 84.8 mm (14.48″ x 9.17″ x 3.34″) |
| Weight (display only) | 2.8 kg (6.17 lb) |
| Compass safe distance | 65 cm (2.1 ft) |
| Mounting type | Gimbal bracket mount or rear mount |
