Description
Swivel Connector - Galvanised
Heavy-duty swivel connectors designed for mooring and marine applications. Hot dipped galvanised for enhanced corrosion resistance, ensuring long-lasting durability and reliable performance under heavy loads.
## Features##
Features
- Hot dipped galvanised for superior corrosion resistance
- Heavy-duty swivel mooring eye & eye design
- Available in multiple sizes to fit various chain diameters
- High Safe Working Load (SWL) for demanding applications
## Features##
## Specifications##
Specifications
| Part No. | Description | Chain Size | A (mm) | B (mm) | C (mm) | Diameter (mm) | SWL (kg) | Note |
|---|---|---|---|---|---|---|---|---|
| 110320A | Swivel mooring HD galvanised eye & eye 10mm diam pivot pin | 10mm | 130 | 109 | 31 | 11 | 1020 | * SWL = Safe Working Load |
| 110320B | Swivel mooring HD galvanised eye & eye 12mm diam pivot pin | 12mm | 170 | 135 | 36 | 14 | 1630 | * SWL = Safe Working Load |
| 110320C | Swivel mooring HD galvanised eye & eye 16mm diam pivot pin | 16mm | 200 | 175 | 40 | 17 | 2360 | * SWL = Safe Working Load |
| 110320D | Swivel mooring HD galvanised eye & eye 20mm diam pivot pin | 20mm | 230 | 190 | 50 | 20 | 3265 | * SWL = Safe Working Load |
## Specifications##
