Airmar PM111C-LHW Wide Beam Low High CHIRP - Mix and Match
Note that this item comes from the USA and may take 7-10 days to deliver, if not in stock.
The PM111LH is a pocket/keel mounted, 2 kW transducer which delivers excellent target resolution, bottom discrimination, and bait and game-fish separation. The PM111LH is packed with a fifteen-element, low-frequency array that operates anywhere between 38 and 75 kHz, delivering great depth capability down to 1829 m (6000'). The single, high-frequency ceramic operates at any frequency between 130 and 210 kHz and has a narrow, 8° to 4°, beam that provide tremendous bottom detail and fish-target discrimination at depths to 457 m (1500').
Features
- Depth and fast-response water-temperature sensing
- 2 kW of power for excellent deep-water performance
- Low frequency: 38 to 75 kHz
- 19° to 10° port-starboard beamwidth
- 10° to 5° fore-aft beamwidth
- Maximum depth of 1829 m (6000')
- High frequency: 130 to 210 kHz
- 8° to 4° beamwidth
- Maximum depth of 457 m (1500')
- 117 kHz of total bandwidth from one transducer
- Covers popular fishing frequencies of 50, 60, and 200 kHz plus everything else in the bandwidth
- Curved-edge design for wet-box installation
- Designed for custom pocket, keel, or welded-tank mounting
- SEALCAST™, seamless, urethane housing for long life underwater
- Also available as in-hull (R111LH) and thru-hull external (R109LH) mounts
- Patented Xducer ID technology
##Specifications##
Specifications
Mounting Style: Tank, Cavity, Pocket/Keel Mount
Frequency Band: Low-High
Max Deadrise Angle: Any
Material: Urethane
Functions: Depth, Temperature
Max Deadrise: Accommodates any deadrise angle based on custom installation
Power Rating: 2 kW
Connector: Bare Wire
Max Vessel LOA: 8 m (25') and above
Display Connector: 0
Hull Material: Solid fiberglass only
High Frequency: 130-210 kHz
Common Use: Fishing, Commercial Fishing
Tilted Element: No
Low Frequency Beamwidth: 10°x19°-5°x10°
Low Frequency: 38-75 kHz
High Frequency Beamwidth: 8°-4°
Single or Dual Frequency: CHIRP-Ready Dual-Band
Country of Origin: USA
Cable-Length: 15 m (49')
Weight: 13.6 kg (30 lb.)
Max Depth: Low frequency- 182 m (600'), High frequency- 457 m (1500')
