Lewmar Hatch - Pilot Silver
Lewmar’s Pilot hatch range has been designed for use in areas such as above helm positions, cockpit roofs or fly-bridge areas. Complementary styling cues have been taken from the Low and Medium Profile hatch range to create a harmonious look.
Features
• Opens up and ventilates enclosed areas
• Conveniently placed opening handlebar mechanism which rotates to seal down the hatch
• Sliding technology from Lewmar’s racing hardware track systems, ensuring minimum friction
• CE approved for Area 3
• Motorised versions available contact your Territory Manager.
Accessories
SP17170241 Track Cam Block & Track Follower
|
BLA Code
|
Size
|
Frame Colour
|
Lower Frame Flange mm
|
Outside X x Y L x W mm
|
Cut Out X1 x Y1 L x W mm
|
Radii R mm
|
Radii R1 mm
|
Height Z mm
|
Acrylic Colour Tint
|
Acrylic00a0 mm
|
Track Length00a0 mm
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| 170170-BLA | 40 | Silver | 15mm | 465 x 491mm | 421 x 421mm | 72.5mm | 42.5mm | 29mm | Grey | 10mm | 284mm |
| 170172-BLA | 60 | Silver | 15mm | 581 x 577mm | 507 x 507mm | 72.5mm | 42.5mm | 29mm | Grey | 10mm | 373mm |
| 170173-BLA | 70 | Silver | 15mm | 701 x 697mm | 625 x 625mm | 72.5mm | 42.5mm | 29mm | Grey | 10mm | 485mm |
| 170174-BLA | 78 | Silver | 15mm | 844 x 790mm | 770 x 720mm | 72.5mm | 42.5mm | 29mm | Grey | 10mm | 638mm |
